RIVERRFPLUS

24-input wireless concentrator

RIVERRFPLUS is a radio concentrator that can be connected directly to an RS-485 serial line for detectors, perimeter transmitters, and wireless remote controls of the HELIOS/VILLEGGIO system. It is compatible with EL.MO. control panels of the ETR, NET, VIDOMO, VIBASIC, and TITANIA series. RIVERRFPLUS significantly expands the potential of a wireless intrusion detection system by allowing a single product to connect up to 18 radio devices in ETR G1 mode or up to 24 radio devices in NET832, VILLEGGIO, and ETR G2 modes. The radio connection range is 80 meters in open fields for detectors or perimeter transmitters and 50 meters in open fields for remote control transmission. RIVERRFPLUS is equipped with a compact plastic container with tamper protection against opening the container.

Features

Maximum number of entries	24
Relay outputs	No
Device Management	Wireless
Electronic outputs	8

Technical details

Versions	Default C1RIV0000800 - C1RIV0000400
Communication interface	RS‑485 ULTRABUS
Compatibility	Detectors, perimeter transmitters, remote controls IV series of the VILLEGGIO and HELIOS systems
Inputs	18 radio devices in reduced mode ETR G1
Inputs	24 radio devices in extended mode for ETR G2, VIDOMO2K, PREGIO, PROXIMA, SUPERIA
Outputs	4 non-programmable outputs for diagnostics + 4 outputs that can be used for control in ET4PLUS, NET4, NET432 and ETR G1 mode
Outputs	8 outputs that can be controlled from the control unit in extended mode for ETR G2, NET5, NET832, NET9, VILLEGGIO, PREGIO, PROXIMA
Wireless range	80 m in open field (50 m for transmissions from remote controls)
Signals	LED for displaying the 8 radio inputs, the radio signal strength, the serial line activity, the Tamper protection status
Power supply	12 Vdc
Power consumption at supply voltage	At rest 30 mA
Power consumption at supply voltage	Maximum 45 mA
Operating temperatures	−10 / +55 °C
Dimensions	L 130 × H 35 × D 46 mm
Weight	100 g
