PREGIO1000BM

PREGIO1000 control unit in a larger metal container

PREGIO1000BM (version CCPRG0201100) is a wired/wireless intrusion control control unit (using GATEWAY2K for NG‑TRX devices) developed on a completely innovative architecture and open to future scenarios and technologies. Thanks to the possibility of extending the number of inputs to 48, PREGIO1000BM is the ideal solution for a variety of installation situations, both domestic and commercial/civil. PREGIO1000BM is equipped with a larger box mod. BOXM. It is based on the principle of integration with the Plug&Play GSM, LTE and LAN modules of the Villeggio system and natively incorporates the best of EL.MO. technology while using only a small part of its extremely high processing capacity. PREGIO1000BM is a “green” control unit , which embraces and highlights highly relevant aspects and issues such as reducing consumption and the resulting economic savings and environmental protection. PREGIO1000BM is certified IMQ‑Allarme EN 50131‑1, EN 50131‑3 grade 3, environmental class II.

Features


Container Metallic
Integrated keypad No
Connection Wired
D-Pulse Yes
EN 50131 grade IMQ certified grade 3
Line Pregio
Scope Residential, small business and retail
Onboard wired inputs 8 (16 split)
Maximum number of inputs 48

Technical details


Versions
Default CCPRG0201100 - CCPRG0200200 - CCPRG0200201 - CCPRG0200209 - CCPRG0200300 - CCPRG0200400 - CCPRG0200800
On-board inputs 8 wired inputs (16 with split function) expandable with GATEWAY2K or RIVER series concentrators via ULTRABUS (RS-485)
Supported inputs 48
On-board outputs 1 programmable output max 100 mA / 12 V detectors power output protected by fuse / 1 programmable relay alarm output (max 3 A) / Connector for 8-output ETRREL board / Terminals for siren control and power supply
Supported outputs 48 (with optional relay modules on RIVER series concentrators), programmable and controllable
Maximum number of users 32
Slots for optional communication modules 1 slot for a module of your choice between MDGSME/MD4GE + 1 slot for an MDLAN module
Other compatible optional modules MDVOICE64 (speech synthesis module), MDRS232 (module for connection to ETREIB)
Compatibility Wired devices, RS-485 ULTRABUS, wireless NG-TRX (via GATEWAY2K)
Areas/Sectors 4 areas with 4 sectors / 2 areas with 8 sectors / 1 area with 16 sectors
Control devices 16 control devices in total on the serial line, to be chosen between keypads, control points, inserters, additional status indicators, of which a maximum of 4 advanced keypads per control unit , to be chosen between KARMA and AURA
Wireless Device Management Via GATEWAY2K (wireless NG-TRX)
Integrated interfaces 1 ULTRABUS RS-485 serial interface
Connectors MiniUSB connector for programming, firmware updates and PC management
Event memory 1000 events
Text-to-speech Built-in with 4 predefined messages (extendable to 64 with optional MDVOICE64 card)
Functions Interfacing with e-Connect / Weekly time programmer
Container Oversized metal protected against opening and removal
Dimensions W 316 × H 305 × D 143 mm
Battery 18 Ah max (not included)
Protection class IP3X
Operating temperatures −10 / +40 °C
Power supply From mains 110-240 Vac 50 Hz, 2.4 A power supply
Current draw 15 mA at idle
Certifications IMQ-Safety Systems EN 50131-1, EN 50131-3 grade 3, environmental class II
