NIRVA

Control keyboard

NIRVA (version OCTAS0103100) is a control keypad on RS-485 ULTRABUS serial bus compatible with EL.MO. ETR, PREGIO, SUPERIA, PROXIMA and VIDOMO2K intrusion control control units . The number of installable keypads depends on the control unit used. It allows control of all system inputs and operating states with the possibility of partial programming of the operating functions. Full programming of the functions is carried out via PC. NIRVA incorporates a front reader for M4 and M4LED proximity keys for rapid arming/ disarming control and it is possible to derive I66 readers from the keypad. It is equipped with a backlit liquid crystal display for viewing control unit status, management and command messages. A backlit keypad, protected by a door, and four system partialization keys allow the various commands necessary for managing the system to be entered; the door with window, when closed, allows protection of the keys and simultaneously viewing the display and LEDs. NIRVA is certified IMQ‑Allarme EN 50131‑3 grade 2‑3 (depending on the system in which it is inserted), environmental class II, EN 50131‑6.

Features


Keys Physical
Connection RS-485

Technical details


Versions
Default OCTAS0103100 - OCTAS0100100 - OCTAS0100101 - OCTAS0103101
Communication interface RS‑485 ULTRABUS
Compatibility PREGIO, SUPERIA, PROXIMA and VIDOMO2K series intrusion control units
Display White backlit LCD display; White backlit keys
Functions 4 system partialization buttons; Built-in proximity key reader; Possibility of connecting an external I66 proximity key reader
Container White
Operating temperatures +5 / + 40 °C
Protection class IP3X
Power supply 12 Vdc
Power consumption at supply voltage 50 mA at idle ; 150 mA maximum
Dimensions L 166 × H 136 × D 33 mm
Weight 290 g
Certifications IMQ‑Security Systems EN 50131‑3, EN 50131‑6 grade 2‑3 (depending on the system in which it is inserted), environmental class II
