Hardwired Intrusion Detection
IZENITH
4-sector inserter capable of partially disabling, controlling and monitoring the intrusion detection system
IZENITH is a 4-sector keypad that can be used to partially arm, control, and monitor the intrusion detection system. It is compatible with the VIDOMO2K, PREGIO, SUPERIA, and PROXIMA control panels. IZENITH features 4 buttons on the front panel for selecting 4 partialization modes, 4 LEDs for displaying the arming and partialization status, and an M4/M4LED proximity key reader with 2 side LED indicators.
Features
| Color | Black |
Technical details
| Versions |
Default
OCPCH0100300
Versione Nera
|
| Communication interface | RS‑485 ULTRABUS |
| Compatibility | VIDOMO2K, PREGIO, SUPERIA and PROXIMA |
| Functions | Selector for programming the identification code and the functionality of the display LED |
| Programming of buzzer signals via specific power supply sequences | |
| Displays | 4 LEDs for operating status and partialization indications. 2 programmable brightness levels |
| Compatible plate | TICINO MAGIC, specific adapters are available for other plates |
| Dimensions | L 21 × H 42 × D 46 mm |
| Weight | 20 g |
| Container | Black (IZENITH) / white (IZENITHB) |
| Power supply | 12 Vdc |
| Power consumption at supply voltage | Maximum 46 mA |
| Certifications | IMQ‑Safety Systems EN 50131‑1, EN 50131‑3 grade 2‑3 based on the system in which it is inserted, environmental class II |
Technical documentation
Select the type of documentation you want to see
Available Documents: 9
