C10SW

The C10SW is a power supply unit in a metal container for intrusion and access control applications; it contains a 13.8 Vdc / 3 A AL3SWJST switching power supply and is equipped with a sophisticated control circuitry for powering field devices and charging compatible self-powered sirens. The front panel features 3 indicator LEDs for battery control (red), output voltage (green) and mains presence (green). It has relay outputs for PRIMARY POWER FAILURE, BATTERY FAILURE and a TAMPER output. It is possible to allocate a 12 V / 7 Ah model B712G or a 12 V / 18 Ah B1812G battery. The small metal container is equipped with tamper protection against opening, while the optional MSW kit is required for protection against being torn from the wall. C10SW complies with EN 50131‑6 level 1 and 2 and environmental class II.
