ANIMA

Capacitive control keypad

ANIMA is a capacitive touch screen keypad that can completely control the intrusion detection system with a simple touch. Its sleek, uniform design comes to life simply by approaching a hand: the keypad immediately appears operational and ready for use. ANIMA offers a minimal and elegant design and the CapSense touch pad allows for an immediate and easy interactive experience. The customizable menu allows you to interact directly with the control unit through simple programming steps, and the integrated proximity key reader makes it easy to arming and disarming the intrusion detection system. The flush-mounting option (optional) is enhanced by a sleek frame. It offers tamper protection against opening and removal.

Features


Keys Touch
Connection RS-485

Technical details


Versions
Default OCTAS0102400 - OCTAS0101600 - OCTAS0101601 - OCTAS0101604 - OCTAS0101605
Communication interface RS‑485 ULTRABUS
Compatibility VIDOMO2K, PREGIO, SUPERIA, PROXIMA series
Display Backlit LCD; CapSense touchpad technology
Functions Customizable menu; Integrated proximity key reader; Tamper protection against opening and removal; Flush mounting with ANIMABOX (optional); 4 system partialization buttons
Operating temperatures −10 / +40 °C
Protection class IP3X
Container Black
Power supply 12 Vdc
Power consumption at supply voltage Idle 55 mA; Maximum 110 mA
Dimensions L 134 × H 95 × D 10 mm
Weight 160 g
Certifications IMQ‑Security Systems EN 50131‑3, EN 50131‑6 grade 2‑3 based on the system in which it is inserted, environmental class II

Technical documentation and software


Select the type of documentation you want to see

Available Documents: 7

Foglio tecnico
Version: 20261020010840
20/10/2026
Datasheet
Version: 20261020010852
20/10/2026
Datasheet
Version: 20261020010901
20/10/2026
Descrizioni Capitolato
Version: 20261020010835
20/10/2026
Product Description
Version: 20261020010847
20/10/2026
Product Description
Version: 20261020010855
20/10/2026
CE - DoP
Version: 1
12/11/2026
